Hydraulic Lift Vacuum Mixer for Sale
Yuanyang hydraulic lift vacuum mixer is a kind of cosmetic mixing equipment, which is the core part of the cosmetic production line.
The hydraulic type is the most popular cosmetic production equipment for making cream, skin-care products, ointment, paste, emulsions, and so on.
Features:
⦁ Composed of a main emulsifying pot, a water pot, and an oil pot.
⦁ With a hydraulic lifting system, vacuum system, and electric control system.
⦁ Suitable for products of 10,000~50,000 cps viscosity.
⦁ Perfect particle size of 2 microns and evenly distributed.
Hydraulic Lift Vacuum Mixer Introduction
The cosmetic manufacturing equipment can be simply called a cosmetic machine,or often called cosmetic mixer. When the materials are under the vacuum condition, it makes use of the high shear homogenizer to distribute one or several to another continuous phase rapidly and evenly. The materials will be processed in the narrow space between the stator and rotor by the strong energy of motion produced by the machine effect.
By the operation of shearing, centrifugal extruding, impacting, breaking, and turbulence for over 100 thousand times per minute, the materials will be dispersed and emulsified instantly and evenly. After reciprocating circulation at high frequency, the fine finished products of stable and high quality without bubbles will be achieved.
This series of cosmetic cream mixing tank is mainly applied in such industries as cosmetic skin care products, food industry, pharmaceutical industry, nanometre materials, electronics, fine chemical industry, etc.
The emulsifying effect of the cosmetic emulsion mixing equipment is more prominent for materials of high viscosity and high solid content.
Hydraulic Lift Vacuum Mixer : key features
Hydraulic Lift Vacuum Mixer Characteristic
| Hydraulic Lift Vacuum Mixer | ||||||||
| Working capacity (L) | Material | Agitator power (KW) |
Speed (rpm) |
Homogenizer power (KW) |
Homogenizer speed (rpm) |
Water pot （L） |
Oil pot （L） |
Main pot system |
| 50L | SS304/316L | 1.1 | 0-65 | 3 | 0-3000 | 40 | 25 | Hydaulic lift |
| 100L | SS304/316L | 1.5 | 0-65 | 3 | 0-3000 | 60 | 50 | Hydaulic lift |
| 200L | SS304/316L | 2.2 | 0-65 | 4 | 0-3000 | 150 | 100 | Hydraulic lift |
| 300L | SS304/316L | 3 | 0-65 | 7.5 | 0-3000 | 250 | 120 | Hydraulic lift |
| 500L | SS304/316L | 4 | 0-65 | 11 | 0-3000 | 350 | 250 | Fixed lid |
| 1000L | SS304/316L | 5.5 | 0-65 | 15 | 0-3000 | 600 | 500 | Fixed lid |
| 2000L | SS304/316L | 7.5 | 0-65 | 18.5 | 0-3000 | 1500 | 1000 | Fixed lid |
| 3000L | SS304/316L | 11 | 0-65 | 22 | 0-3000 | 2000 | 1000 | Fixed lid |
| 5000L | SS304/316L | 15 | 0-65 | 37 | 0-3000 | 3000 | 2000 | Fixed lid |
| Key function includes: vacuum, scrapers mixing, homogenizing, heating. Two ways of homogenizer installation: on top or at bottom Two ways of heating: electric heating and steam heating; steam heating requires a steam generator Water pot and oil pot are optional; choose according to actual needs. Other optional function: circulation system, load cell system, water flow meter system |
||||||||
Hydraulic Lift Vacuum Mixer General Application
Hydraulic Lift Vacuum Mixer options
FAQs
Hydraulic Lift Vacuum Mixer
What’s the thickness of the vacuum mixer?
The thickness depends on the machine type, capacity of the tank, and the function. For example the standard 500L vacuum homogenizer tank electric heating with double jackets, there are three layers. The inner layer is 5mm, middle layer is 4mm, the outer layer is 2mm. If clients has special requirement, we can customize accordingly.
What’s the maximum height that the lid can lift up to? And how high it is when cover closed?
The dimension is different for different capacity. For example, the 500L height is 2.48m when cover closed, the height is 3.6m when cover lift up.
How do you pack for the cosmetic emulsifier?
The emulsifying equipment will be wrapped with film first, then packed with wooden case. The machine is well-protected during shipment.
What’s the feature of water tank and oil tank?
The water tank and oil tank are for pre-treatment for better mixing efficient when sucked into main emulsifying tank. The two tanks are often equipped with bottom dispersing plate or top mixing and double jackets for heating and insulation.
What’s the designed capacity and working capacity for the 500L hydraulic vacuum mixer?
The designed capacity is 540 liters, the working capacity is 500 liters.
